Certified to
NSF/ANSI/CAN 60
Calcite is a crushed and screened white marble media which can inexpensively be used to neutralize acidic or low pH waters to a neutral, less corrosive effluent.
Made in The USA
Features
- Naturally occurring material
- Low uniformity coefficient for maximum contact for controlled pH correction
- Slower reacting for controlled pH correction
- Inexpensive
Calcite is a naturally occurring calcium carbonate media. One of the advantages of Calcite is its self-limiting property. When properly applied, it corrects pH only enough to reach a non-corrosive equilibrium. It does not overcorrect under normal conditions. Upon contact with Calcite, acidic waters slowly dissolve the calcium carbonate to raise the pH which reduces the potential leaching of copper, lead and other metals found in typical plumbing systems. Periodic backwashing will prevent packing, reclassify the bed and maintain high service rates. Depending on pH, water chemistry and service flow, the Calcite bed will have to be periodically replenished as the Calcite is depleted.
As the Calcite’s calcium carbonate neutralizes the water, it will increase hardness and a softener may become necessary after the neutralizing filter.
Calcite can be effectively combined with Clack Corosex to combine the high flow neutralization properties of Corosex, along with the slower reacting low flow properties of Calcite, increasing the ability to correct low pH.
Specifications
Physical properties | |
Bulk Density | 90 lbs./cu. ft |
Apparent Density | |
Effective Size | 0.4 mm |
Uniformity Coefficient | 1.5 |
Mesh Size | 16 x 40 |
Acid Solubility | |
Caustic Solubility | |
Type | |
Crystal System | |
Specific Gravity | 2.7 |
Ash Content | |
Iodine Number | |
Moisture | |
Moisture as packed | |
Particle Shape | |
pH | |
Hardness | 3.0 (Mohs scale) |
Composition | |
Porosity | |
Screen Grading | |
Color | Near white |
Conditions for operation | |
Water pH range | 5.0-7.0 |
Maximum Water Temperature | |
Dissolved Oxygen Concentration | |
Bed | Gravel support bed is recommended |
Bed depth | 24-30 in. |
Minimum Bed depth | |
Freeboard | 50% of bed depth (min.) |
Service flow rate | 3-6 gpm/sq. ft. but may be modified to adapt to local conditions |
Backwash flow rate | 8-12 gpm/sq. ft. |
Backwash | |
Backwash bed expansion | 12% minimum |
Capacity | |
Air/Water Scour | |
Raw Water Rinse | |
Other |
Ordering Information
Code | Model | Cu. Ft./Bag | Weight/Cu. Ft. Lbs (Approximate) |
Bags/Pallet | Weight/Pallet Lbs |
Pallet Dimensions |
A8021-01 | Calcite | .55 (50 lbs.) | 90 | 49 | 49 | 48” x 40” x 32” |
